APPLICATIONS:

Industrial and Electric Vehicles
Public Transportation
Bus, Rail, Airborne, Navy
   communication devices (e.g. GPS)
   onboard computer
   barcode readers
   headlights and break lights on forklift trucks
   no airborne communication interference
Airport Service Vehicles
   e.g. Aeroplane wing de-icer
Recreational vehicle
   (RV, Marine, Yachting)
Harsh Environment Applications

Mobile or battery based electronic equipment

Motor-controller for DC-Motors
Test, Measuring, and other Instrumentation Control Systems

INPUT:
28V to 56V
(other voltages up to 96V on request)

OUTPUT:
24.4V / 8A
for 12V model see SDC144.1 (other voltages on request)

POWER:
max. 200W

WEIGHT:
8.4oz. (240 grams)

DIMENSIONS:
3.95" x 2.61" x 0.67"
(100 x 66 x 17mm)

Adjustable Output (Dimmer)

LEDs on Input and Output

Light weight

High power density

Common Input and Output Ground for higher efficiency and low costs RF

Input and Output Filters

Input Transient and Reverse Polarity Protection

Short Circuit Protection

Input Fuse

Over temperature shutdown

Humidity protected

Wide temperature range -40 to +80 degr. C

Low profile design

High Efficiency (94% typ; 96% max)

Vibration Tight

Screw Terminals
